Plastic Mulch Layer For Cat 1. 3-PT Tractors

Número de Parte del Fabricante: AB-9020

Tilmor Part Number: AB-9020

par Tilmor Ox Logo - Gray

À Partir de $4,681.00

The Tilmor plastic layer is a modular design for laying 3', 4' and 5' plastic and up to two rows of standard drip tape. The mulch layer can be purchased as a standalone unit with the bed shaper and closing discs or it can be purchased with the optional hiller discs allowing you to preform the bed in one pass. The innovative design includes the following features:
  • Holds up to two rolls of drip tape
  • Built in carrier for second roll of plastic mulch
  • Adjustable bed shaper for laying 1 meter, 3' and 4' plastic mulch.
  • Max diameter of plastic rolls: 9-1/4"
  • No tools required, easy adjustment for tire tension and closing discs.
  • Integrated holder for carrying a standard ground shovel.
  • One drip tape burier AB-9011
  • Designed to lay Fabric as well
For proper use it is required to preform the bed with hiller discs before using the plastic layer.

Plastic Rolls Greater Than 9:1/4" in Diameter Will Not Fit
Hiller Discs and Plastic Layer System
Shop 520 Tilmor Tractor Layer

Toolbar

Category 1 Toolbar Render

The Category 1 Toolbar comes in two specific lengths, 64 and 76 inches. Select the length based on desired working width.

Hiller Discs

Hiller Disc Set-up for layer

Options:

Produit Prix (ch.) Quantity Disponibilité
Drip Tape Roller Mount
AB-9011 		CA$91.00
En stock
44lb/20kg Weight with Latch
AT-9001 		CA$138.00
En stock
2,400' Plastic Roll, 1 mil, Dim Emb
PA-9060 		CA$107.80
Ce produit est en rupture de stock
Toolbar To Toolbar Spacer - 10.5in
AA-9093 		CA$234.00
Est. de la date d'expédition: May 13, 2025

Prix:

Commande en attente

Est. de la date d'expédition: Jun 19, 2025

Expédition en 1-2 jours ouvrables

Ce produit, ou ces configurations, n'est pas en stock actuellement.

Ce produit ou ces configurations arrive bientôt.

Appelez pour la disponibilité

Quantité


Compare: Tilmor Layer CropCare Layer
tilmor layer plastic layer cropcare
Recommended Min. Horsepower 25 HP 45 HP
Tractor Passes Required 1-2 1
Plastic Laying Width 3-4 ft. plastic 3-5 ft. plastic
Max. Plastic Roll Diameter 9-1/4 in. None
Bed Shaper Height Adjustable No Yes up to 10"
Nom Cat 1. - 64 inch Hiller Bed Prep Set-Up Drip Tape Roller Mount 44lb/20kg Weight with Latch Plastic, Roll 1 mil, Dim Emb Toolbar To Toolbar Spacer - 10.5in Aqua Traxx, 5/8 x 7500', 8 mil, 6” spacing .67 flow Aqua Traxx 5/8 x 7500', 8 mil, 12" spacing .45 flow
Image Category 1 Toolbar Render Hiller Disc Set-up for layer 44lb/20kg Tilmor Tractor Weight Plastic Mulch toolbar connectors modbar toro-aqua-traxx toro-aqua-traxx
Numéro de Pièce Tilmor KIT-1029 KIT-1106 AB-9011 AT-9001 PA-9060 AA-9093 PB-1565 PB-1566
GTIN 00850002085112
Numéro de la Pièce du Fabricant N/A N/A N/A N/A N/A N/A 3104 3102
Poids 67.3 Kg. 20.75 Kg. 6.5500 Kg. 44.3500 Kg. 58.0000 Kg. 20.1500 Kg. 54.7000 Kg. 54.7000 Kg.
Résidents de la Californie ATTENTION: Cliquez ici pour plus d'informations sur la Proposition 65
Garantie Garantie limitée d'un an au propriétaire d'origine. Cliquez ici pour plus d'informations.
