Basket Weeder

Manufacturer Part Number:

Tilmor Part Number:

by Tilmor Ox Logo - Gray

Starting at $2,251.00

The Basket Weeder is typically used for inter-row weeding, with wire baskets spaced apart to allow the crop row to pass between them.

Basket weeders may also be used to prepare a stale seedbed by placing the baskets together and running over the entire width of the seedbed.

60" basket weeders allow for up to 53" of cultivation

80" basket weeders allow for up to 73" of cultivation

Ships via UPS in multiple boxes. Assembly Required.
Basket Weeder for Tilmor Power Ox or Planet Jr.
Basket Weeder for Walk Behind
spyder basket for stalebedding
Hard Soil? Try With Spyders
Mid Mount Tool Bar Kit for Basket Weeder
Mid Mount Tool Bar Kit

Frame Size

The 60 inch Basket Weeder frame is constructed of two side plates, two stainless steel hex shafts, and one set of sprockets and chain. The side plates may be adjusted infinitely along the length of the hex shafts and are typically set to match the width of the seedbed. View Narrow Assembly Instructions

The 80 inch Basket Weeder frame is constructed of two side plates, one center support plate, two stainless steel hex shafts, and a set of sprockets and chains on each end (2). The side plates may be adjusted infinitely along the length of the hex shafts and are typically set to match the width of the seedbed. View Wide Assembly Instructions

Mount

Toolbar mount for Basket Weeder

For mounting on a 2" square tool bar on Tilmor or category 1 tractors with top link.

Toolbar mount for Basket Weeder

For mounting on a 2" square tool bar on mid mount tractors. Tilt adjustment for tractors without top links.

For mounting on a 2-1/4" Diamond tool bar. Slotted holes allow tilt adjustment for tractors without top links.

No mounts included to mount the basket weeder frame to toolbar. You must provide your own method of mounting.

Mount

Toolbar mount for Basket Weeder

For mounting on a 2" square tool bar on Tilmor or category 1 tractors with top link.

Toolbar mount for Basket Weeder

For mounting on a 2" square tool bar on mid mount tractors. Tilt adjustment for tractors without top links.

For mounting on a 2-1/4" Diamond tool bar. Slotted holes allow tilt adjustment for tractors without top links.

No mounts included to mount the basket weeder frame to toolbar. You must provide your own method of mounting.

Chain Guard

Tilmor Basket Weeder Chain Guard

Use the chain cover to keep the chain clear of crops or other field debris.

Standard Baskets

Tilmor basket wires are made of ¼” zinc-plated spring steel in widths of 4, 5, 6, 7, 8, 9 and 10 inches. Configure the Basket Weeder to meet your specific needs or Contact Us for assistance:

  1. Select the basket width to match the crop row width less the desired clearance (ex.: a 13 inch crop row minus 3 inches of clearance on each side of the basket requires a 7 inch basket).
    Note: There must be a front and rear basket, so two 7 inch baskets should be added.
  2. Select the number of baskets needed to work both sides of each row (ex.: number of rows + 1 = number of baskets pairs. 3 rows requires a total of 8 baskets).

      3. Product Price (ea) Quantity Availability
      3 Inch Basket
      KIT-1113       		$173.00
      		In stock
      4 inch Basket
      KIT-1012       		$173.00
      		In stock
      5 inch Basket
      KIT-1005       		$175.00
      		In stock
      6 inch Basket
      KIT-1006       		$177.00
      		In stock
      7 inch Basket
      KIT-1007       		$179.00
      		In stock
      8 inch Basket
      KIT-1008       		$184.00
      		In stock
      9 inch Basket
      KIT-1009       		$187.00
      		In stock
      10 inch Basket
      KIT-1010       		$189.00
      		In stock
      11 Inch Basket
      KIT-1761       		$191.00
      		In stock
      12 inch Basket
      KIT-1011       		$191.00
      		In stock

Price:

Est. ship date: Dec 5, 2024

Ships in 2-3 business days

This product, or its configuration, is out of stock. Call for Availability.

This product or its configuration is coming soon.

Call for availability

Qty
Name 60 inch 80 inch 3 Inch Basket 4 inch Basket 5 inch Basket 6 inch Basket 7 inch Basket 8 inch Basket 9 inch Basket 10 inch Basket 11 Inch Basket 12 inch Basket Basket Weeder Chain Cover
Image Basket Assembly for Tilmor Basket Weeder Basket Assembly for Tilmor Basket Weeder Basket Assembly for Tilmor Basket Weeder Basket Assembly for Tilmor Basket Weeder Basket Assembly for Tilmor Basket Weeder Basket Assembly for Tilmor Basket Weeder Basket Assembly for Tilmor Basket Weeder Basket Assembly for Tilmor Basket Weeder Basket Assembly for Tilmor Basket Weeder Tilmor Basket Weeder Chain Guard
Tilmor Part Number KIT-1003 KIT-1004 KIT-1113 KIT-1012 KIT-1005 KIT-1006 KIT-1007 KIT-1008 KIT-1009 KIT-1010 KIT-1761 KIT-1011 AW-9055
GTIN 00850002085051 00850002085068
Manufacturer Part Number N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
Weight 56.95 lbs. 68.3 lbs. 9.95 lbs. 9.85 lbs. 9.95 lbs. 10 lbs. 10.25 lbs. 10.5 lbs. 10.65 lbs. 10.8 lbs. 7.8 lbs. 11.1 lbs. 10.0000 lbs.
California Residents WARNING: Click here for more information on Proposition 65
Warranty Limited 1 year warranty to original owner. Click here for more information.
