A1 Carbide Blades for Einbock Cultivators

Manufacturer Part Number:

Tilmor Part Number:

by Boehlerit Logo

Starting at $62.20

Maximize your row crop cultivator efficiency by extending blade life by up to 10 times! Invest in carbide tools for optimal working quality and high wear protection.

Blade Size

Maximize your row crop cultivator efficiency by extending blade life by up to 10 times! Invest in carbide tools for optimal working quality and high wear protection. These blades mount onto 53.5° Einbock shanks.

Blade Width: 4in
Shank Angle: 53.5°
Single Square Hole Diameter: 0.42in
HS100A1

  • Beaver tooth (self sharpening) effect
  • Carbide segments cut continuously from start to end of tool life
  • Constant working width until end of tool life
  • Serrated carbide segments for even better cutting through or tearing out
  • Slightly lower carbide tip for better soil penetration

Maximize your row crop cultivator efficiency by extending blade life by up to 10 times! Invest in carbide tools for optimal working quality and high wear protection. These blades mount onto 53.5° Einbock shanks.

Blade Width: 4.75in
Shank Angle: 53.5°
Single Square Hole Diameter: 0.42in
HS120A1

  • Beaver tooth (self sharpening) effect
  • Carbide segments cut continuously from start to end of tool life
  • Constant working width until end of tool life
  • Serrated carbide segments for even better cutting through or tearing out
  • Slightly lower carbide tip for better soil penetration

Maximize your row crop cultivator efficiency by extending blade life by up to 10 times! Invest in carbide tools for optimal working quality and high wear protection. These blades mount onto 53.5° Einbock shanks.

Blade Width: 5.5in
Shank Angle: 53.5°
Single Square Hole Diameter: 0.42in
HS140A1

  • Beaver tooth (self sharpening) effect
  • Carbide segments cut continuously from start to end of tool life
  • Constant working width until end of tool life
  • Serrated carbide segments for even better cutting through or tearing out
  • Slightly lower carbide tip for better soil penetration

Maximize your row crop cultivator efficiency by extending blade life by up to 10 times! Invest in carbide tools for optimal working quality and high wear protection. These blades mount onto 53.5° Einbock shanks.

Blade Width: 6.25in
Shank Angle: 53.5°
Single Square Hole Diameter: 0.42in
HS160A1

  • Beaver tooth (self sharpening) effect
  • Carbide segments cut continuously from start to end of tool life
  • Constant working width until end of tool life
  • Serrated carbide segments for even better cutting through or tearing out
  • Slightly lower carbide tip for better soil penetration

Maximize your row crop cultivator efficiency by extending blade life by up to 10 times! Invest in carbide tools for optimal working quality and high wear protection. These blades mount onto 53.5° Einbock shanks.

Blade Width: 7in
Shank Angle: 53.5°
Single Square Hole Diameter: 0.42in
HS180A1

  • Beaver tooth (self sharpening) effect
  • Carbide segments cut continuously from start to end of tool life
  • Constant working width until end of tool life
  • Serrated carbide segments for even better cutting through or tearing out
  • Slightly lower carbide tip for better soil penetration

Maximize your row crop cultivator efficiency by extending blade life by up to 10 times! Invest in carbide tools for optimal working quality and high wear protection. These blades mount onto 53.5° Einbock shanks.

Blade Width: 7.875in
Shank Angle: 53.5°
Single Square Hole Diameter: 0.42in
HS200A1

  • Beaver tooth (self sharpening) effect
  • Carbide segments cut continuously from start to end of tool life
  • Constant working width until end of tool life
  • Serrated carbide segments for even better cutting through or tearing out
  • Slightly lower carbide tip for better soil penetration

Bolt

M10X40 Saddle Bolt
Diameter: 10mm
Fastener's Length: 40mm
Description: DIN608-10.9

Nut

10mm Flanged Nut (M10)
Description: DIN633-10

Price:

Est. ship date: Jan 4, 2025

Ships in 2-3 business days

This product, or its configuration, is out of stock. Call for Availability.

This product or its configuration is coming soon.

Call for availability

Qty
carbide blade
A No smear layer formation
B Slightly lower carbide tip for better soil penetration
C Carbide segments cut continuously from start to end of tool life
D Constant working width until end of tool life
E Reinforced ground shares even for the toughest conditions
Name Carbide Blade HS100A1 4in 53.5degree angle for Einbock Carbide Blade HS120A1 4.75in wide at 53.5degree angle for Einbock Cultivator Carbide Blade HS140A1 5.5in 53.5degree angle for Einbock Cultivator Carbide Blade HS160A1 6.25in at 53.5degree angle for Einbock Cultivator Carbide Blade HS180A1 7in wide at 53.5degree angle for Einbock Cultivator Carbide Blade HS200A1 7.88in wide at 53.5degree angle for Einbock Cultivator M10X40 Saddle Bolt DIN608-10.9 M10 Flanged Nut
Tilmor Part Number PB-1829 PB-1830 PB-1831 PB-1832 PB-1833 PB-1834 PB-1835 PB-1818
Manufacturer Part Number 5158572 5172471 5153343 5153355 5153363 5172462 5187849 5154988
Weight 0.5500 lbs. 0.6200 lbs. 0.6800 lbs. 0.7500 lbs. 0.8600 lbs. 0.9100 lbs. 0.0880 lbs. 0.0220 lbs.
California Residents WARNING: Click here for more information on Proposition 65
Warranty Limited 1 year warranty to original owner. Click here for more information.
